Carel PGD0000T00 PCO Graphic Display
SKU
PGD0000T00
Brand
Carel
$558.23
Need Help
Assistance Available
Easy Returns
Quick & Hassle Fee
Guaranteed Fit
Always the correct part
Overview
The pGDT graphic display is an electronic device that is compatible with applications that used the previous PCOT line terminals, while providing complete management of graphics as in the pGD family, such as the display of icons (defined during application program development) and the management of international fonts in two sizes. Connection to the pCO controller is available over the RS485 network using the pLAN protocol.
More Information On pGD Graphic Displays
All pGD and pGN graphic displays can be interchanged with each other. They use a RS485 connection to connect to pCO / c.pCO sistema controllers.
pGD, pGD1, pGN, and pGN1 Displays
pGD, pGD1, pGN, and pGN1 displays feature a keypad that repeats the symbols used on the pCO5+/pCO5+HS/c.pCO controllers.
pGD and pGN displays are 120 x 32 pixels, while the pGD1 and pGN1 displays are 132 x 64 pixels.
pGD displays have green backlighting
pGD1 offers green and white backlighting
pGN series are all white backlit
pGDE And pGNE Displays
pGDE and pGNE displays use the symbols from the built-in keypad on the pCO5/5+/c.pCO controllers
Both series have 132 x 64 pixel displays and white LED backlighting.
pDG-I pCOI Enclosure
pGD-I integrates pGD graphic display technology inside the pCOI plastic case. This allows the previous layout to be used, while exploiting the technology and performance of the pGD.
The pCOI Enclosure version is available for the pGD, pGD1, pGN and pGN1 series.
Specifications
| Manufacturer | Carel |
|---|---|
| Product Type | Refrigeration |
| pGD Series | pGDT |
| pGD Display Backlighting Color | Green |
| Mounting | Wall or Duct |
| Screen Resolution | 120 x 32 Pixels |
| Buzzer | Yes |
| Logo | Yes |
| Product Length | 6.75 inches (17.145 cm) |
| Product Width | 4.75 inches (12.065 cm) |
| Product Height | 1.75 inches (4.445 cm) |
| Product Weight | 0.95 lbs (0.431 kg) |
| Country of Origin | Italy |
| Schedule B Number | 9032.90.6180 |
| Shipping Length | 8.5 inches (21.590 cm) |
| Shipping Width | 6.75 inches (17.145 cm) |
| Shipping Height | 4.5 inches (11.430 cm) |
